ATV CF500-2/2A

CF500-2/2A

CF500-2 (single seat) and CF500-2A (dual seat) are independently developed by CFMOTO equipped with a low RPM, high torque and powerful output ATV engine, 4-wheel drive, and 4-wheel independent suspension, which highlights the vehicle’s high cross-country ability applied in military enhancements, forest patrol and field exploration.

• Single cylinder, liquid-cooled, four-valve, four-stroke, 500cc engine;
• Featuring front and rear shaft transmission;
• Four-wheel independent suspension;
• Electrical/recoil starter; Pressure relief for engine easy staring;
• Automatic CVT transmission; gear shift with H/L/N/R/P;
• Electrically-controlled 4×4 4×2 shift with front different lock;
• Comes standard with dashboard, headlight, power output jack and front bumper.
• May be shown with additional modifications and/or accessories

Engine

Engine Type : Single-cylinder, 4-valve, SOHC, LIQUID COOLED

Displacement : 493cc

Bore & Stroke : 87.5x82mm

Compression Ratio : 10.2:1

Maximum Torque : 38.8N.m/5500 r/min

Maximum Power : 24kW/ 6500r/min

Fuel Supply : Carburetor

Ignition : CDI

Starting : Electric & Recoil Start

Transmission : CVT

Lubrication : Pressure & Splash

Cooling System : Liquid cooled

Dimensions and Capacities

L x W x H : CF500-2: 2185x1170x1230/CF500-2A: 2385x1170x1230

Wheelbase : CF500-2: 1490mm/CF500-2A: 1690mm

Seat Height : 900mm

Ground Clearance : 275mm

Curb Weight : CF500-2: 357kg/CF500-2A: 370kg

Max Payload : Capacity 210kg

Fuel Capacity : 19L

Chassis

Wheels Front : 12×6.0 AT Cast Light Alloy

Wheels Rear : 12×7.5 AT Cast Light Alloy

Tyres Front : AT25×9-12 40J 40kPa Tubeless

Tyres Rear : AT26×9-12 47J 40kPa Tubeless

Suspension Front : Double wishbone Independent Suspension, Coil Spring Oil Damp Shock Absorber

Suspension Rear : Double wishbone Independent Suspension, Coil Spring Oil Damp Shock Absorber

Brakes Front : Hydraulic Braking, Double Disc 220 × 3.5mm with felly brakes

Brakes Rear : Hydraulic Braking, Single 150 × 7.5mm, centralized brakes

Others

LCD Dashboard : Optional

2WD & 4WD Switch : Standard

Differential Lock : Standard
